Madagascar Railway No. 35 to 40 and 61 to 68
go back
Madagascar | 1916
14 produced
Image of locomotive
Locomotive Cyclopedia of American Practice, 1922

The first five Mallets for the Madagascar Railway were built in 1916 by Baldwin and carried the works numbers 44331 to 44334, 44609 and 44610. They had to be suitable for the winding lines between the east coast and the capital Antananarivo. Requirements included the ability to haul a 110-tonne train up a 2.5 percent incline at 12 km/h. They had two groups of two axles each and water tanks along the sides of the boiler, while the wood was stored in an additional tender. A Belpaire firebox was used to better utilize the heat of the wood.

The six locomotives of the original Baldwin variant were numbered 35 to 40. Nine years later, they ordered eight more with a superheater. Now, the order went to SACM in France. These locomotives carried the works numbers 7391 to 7398 and were numbered 61 to 68 by the railway. The high pressure cylinders now had a diameter that was 20 mm bigger.

Variant35-4061-68
General
Built19161925
ManufacturerBaldwinSACM
Wheel arr.0-4-4-0T (Four Coupled Mallet)
Gauge3 ft 3 3/8 in (Meter gauge)
Dimensions and Weights
Wheelbase15 ft 3 7/8 in
Rigid wheelbase4 ft 7 1/8 in
Total wheelbase29 ft 11 1/16 in30 ft 2 3/16 in
Service weight70,548 lbs71,804 lbs
Adhesive weight70,548 lbs71,804 lbs
Total weight93,586 lbs95,868 lbs
Axle load17,637 lbs17,968 lbs
Water capacity502 us gal555 us gal
Fuel capacity6,614 lbs (wood)
Boiler
Grate area12.8 sq ft
Firebox area69.3 sq ft69.4 sq ft
Tube heating area697.7 sq ft540.8 sq ft
Evaporative heating area767 sq ft610.2 sq ft
Superheater area181.4 sq ft
Total heating area767 sq ft791.6 sq ft
Variant35-4061-68
Power Plant
Driver diameter39.8 in
Boiler pressure174 psi
Expansion typesimple
Cylindersfour, front: 11 x 19 11/16 in
rear: 16 3/4 x 19 11/16 in
four, front: 11 13/16 x 19 11/16 in
rear: 16 3/4 x 19 11/16 in
Power
Power sourcesteam
Estimated power335 hp (250 kW)402 hp (300 kW)
Starting effort29,396 lbf30,712 lbf
Calculated Values
steam locomotive
freight
Mallet
tank and tender
