loco-info.com - General Electric PowerHaul

Allgemein
Bauzeit	seit 2008
Hersteller	General Electric	General Electric, Tülomsaş	UGL Rail
Achsfolge	C-C
Spurweite	4 ft 8 1/2 in (Normalspur)		3 ft 6 in (Kapspur)

Maße und Gewichte
Länge	71 ft 2 3/4 in	71 ft 2 5/16 in	68 ft 5 5/8 in
Dienstmasse	284,396 lbs	277,782 lbs	268,964 lbs
Reibungsmasse	284,396 lbs	277,782 lbs	268,964 lbs
Achslast	47,399 lbs	46,297 lbs	44,827 lbs

Kessel

Kessel

Variante	PH37ACmi	PH37ACi	PH37ACmai

Triebwerk

Triebwerk

Antrieb
Antrieb	dieselelektrisch
Max. Geschwindigkeit	75 mph
Anfahrzugkraft	120,048 lbf	122,296 lbf
Motor	GE PowerHaul P616
Bauart Motor	V16 Diesel
Tankinhalt	1,585 us gal (Diesel)	2,378 us gal (Diesel)	2,774 us gal (Diesel)
Motorleistung	3,688 hp (2,750 kW)

Berechnete Werte
Adhäsionskoeffizient	1 : 2.37	1 : 2.27	1 : 2.20
Leistungsgewicht	0.0130 hp/lb	0.0133 hp/lb	0.0137 hp/lb
Reibungsmasse/Gesamt	1 : 1.00

Diesellok

Güterzug

Personenzug

GE PowerHaul

Drehstrom
