Tanganjika Railways class DL
East African class 23
go back
Tanzania | 1923
6 produced
Image of locomotive
flickr/Historical Railway Images

The class DL consisted of six 4-8-0 tender locomotives built by Beyer, Peacock & Co. in 1923. They were derived from the Uganda Railway class GD and carried the works numbers 6128 to 6133. Their boilers were equipped with a Belpaire firebox and a Robinson superheater. Originally built for wood burning, they were actually fired with coal instead that had a sufficient calorific value. Later they were rebuilt to burn oil. Their original running numbers were 200 to 205 and were later changed to 300 to 305. When the east African Railways were founded in 1948, they became class 23, with the numbers 2301 to 2306. 2302 has been preserved and now is on static display in Nairobi.

General
Built1923
ManufacturerBeyer, Peacock & Co.
Wheel arr.4-8-0 (Twelve-wheeler)
Gauge3 ft 3 3/8 in (Meter gauge)
Dimensions and Weights
Wheelbase21 ft 5 in
Rigid wheelbase12 ft
Service weight107,072 lbs
Adhesive weight84,448 lbs
Total weight171,360 lbs
Water capacity3,002 us gal
Fuel capacity2,426 lbs (oil)
Boiler
Grate area18.3 sq ft
Firebox area129 sq ft
Tube heating area957 sq ft
Evaporative heating area1,086 sq ft
Superheater area249 sq ft
Total heating area1,335 sq ft
Power Plant
Driver diameter43 in
Boiler pressure165 psi
Expansion typesimple
Cylinderstwo, 18 x 23 in
Power
Power sourcesteam
Estimated power900 hp (671 kW)
Starting effort24,306 lbf
Calculated Values
steam locomotive
freight
