Swedish State Railways T
later Ta and Finnish Railway Hr2
go back
Sweden | 1899
53 produced
Ta 664, built in 1901 by NoHAB
Ta 664, built in 1901 by NoHAB
Järnvägsmuseet, JvmKDAJ07623

For heavy passenger and freight trains, the SJ ordered ten 4-6-0 locomotives from Richmond Locomotive Works, since the Swedish builders were busy at that time. They were two-cylinder compounds with a saturated taper boiler. Boiler pressure of these first ten was 180 psi or 12.4 bars. Between 1901 and 1905, 29 more were built by NoHAB and 14 by Motala Verkstad. These had a boiler pressure of 13.5 bars. The designation of this class was T. After the introduction of the Tb with a larger boiler, the T was renamed to Ta. In the twenties the Ta received parallel boilers to make them as powerful as the Tb. But withdrawals already started in 1927 and by 1942, only four were remaining.

Some were sold to the Finnish State Railways after their withdrawal to address a severe locomotive shortage in World War II. There they had to be re-gauged to broad gauge and needed more modifications before they could be used as Hr2. After the war, they were used for some more years and scrapped between 1950 and 1953. The four locomotives still in service in Sweden again became the T in 1942, while the Tb became the T2. Since both now had similar boilers, they were combined to the new class B5 in 1952. The last ones were scrapped in 1964.

VariantRichmondNoHAB, Motala Verkstad
General
Built18991901-1905
ManufacturerRichmondNoHAB, Motala Werkstad
Wheel arr.4-6-0 (Ten-wheeler)
Gauge4 ft 8 1/2 in (Standard gauge)
Dimensions and Weights
Length54 ft 2 13/16 in53 ft 2 in
Length loco32 ft 7 5/16 in
Wheelbase23 ft 3 7/16 in
Rigid wheelbase12 ft 7 15/16 in
Total wheelbase43 ft 1 1/4 in
Empty weight112,987 lbs
Service weight121,563 lbs125,002 lbs
Adhesive weight86,862 lbs88,714 lbs
Total weight187,426 lbs197,093 lbs
Water capacity3,963 us gal3,698 us gal
Fuel capacity13,228 lbs (coal)11,464 lbs (coal)
Boiler
Grate area19.1 sq ft
Firebox area112.7 sq ft
Tube heating area1,318.6 sq ft
Evaporative heating area1,431.3 sq ft
Total heating area1,431.3 sq ft
VariantRichmondNoHAB, Motala Verkstad
Power Plant
Driver diameter62 in
Boiler pressure180 psi196 psi
Expansion typecompound
Cylinderstwo, HP: 20 x 24 in
and LP: 31 x 24 in
Power
Power sourcesteam
Estimated power711 hp (530 kW)751 hp (560 kW)
Top speed47 mph
Starting effort16,713 lbf18,200 lbf
with start valve20,056 lbf21,840 lbf
Calculated Values
steam locomotive
passenger
freight
